Pirnt Speed |
160mm/sec (MAX) |
Resolution |
Inner Code |
Supported 11 types font size |
Print parameters |
Support to download the Logo trademark |
Media Sensor |
Dual-media sensors: transmissive and reflective |
One-dimensional code |
UPC-A / UPC-E / JAN13 (EAN13) / JAN8 (EAN8) / CODE39 / ITF / CODABAR / CODE93 / CODE128 |
Two-dimensional code |
QR Code, PDF417 |
Printer Driver |
Win2003 / WinXP / Win7 / WIN8 / WIN10 / MACOS ; Support IOS / Android |
Paper |
|
Thermal Paper Types |
continuous paper, label paper, folded paper, tag paper |
Effective Print Width |
100mm (Max 800 points) |
Available Max Paper Width |
110 ± 0.5mm |
Paper Thickness |
0.06-0.30 mm |
Electrical |
Charging Method |
external charger DC 24V/2.5A |
Print Head |
Reliability |
Print Reliability |
100000000 pulse / dot or 50km |
Physical |
|
Printer Dimension |
Unit Weight |
1.50kgs (with accessories) |
Pieces Per CTN |
12 Pieces |
Printer Color |
White |
CTN Dimension |
Gross Weight |
18kgs |
Environmental |
|
Operating Temperature |
+0 ℃ ~ 50 ℃ (no condensation allowed) |
Working Humidity |
20% ~ 85% RH (no condensation allowed) |
Storage Temperature |
-20 ℃ ~ 60 ℃ (no condensation allowed) |
Storage Humidity |
5% ~ 95% RH (no condensation allowed) |
Mechanical Noise |
Accessories |
|
USB Cable |
1 x 1M Cable |
CD Driver |
1 Piece |
Power Adapter |
1 Piece |
Power Cable |
1 Piece |
